Samsung Galaxy S23 Earpiece Speaker Replacement

Note that repairing the earpiece speaker will compromise your device's water resistance and void its IP rating.

  • Follow this guide to replace the earpiece speaker.
  • The back cover adhesive must be reapplied carefully after the repair to retain any remaining water resistance.

Step 1 | Prepare your phone for disassembly

Step 1 image
Thumbnail 1
Thumbnail 2

A charged lithium-ion battery can pose a safety risk.

Allow the battery to drain below 25% charge level if possible.

If the battery is swollen, take necessary precautions before proceeding.

  • Unplug all cables from your phone.
  • Press and hold both the side key and the volume down button.
  • Select "Power off" to shut down your phone completely.

Step 2 | Heat the right edge

Step 2 image

Apply a heated iOpener to the right edge of the back cover for 2 minutes to loosen the adhesive.

  • The iOpener can be replaced with alternative tools, such as a hair dryer, heat gun, or hot plate.
  • Avoid overheating the phone to prevent damage to the display and internal battery.

Step 3 | Insert an opening pick

Step 3 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Apply a suction handle to the back cover, centered at the right edge.

  • Pull up on the suction handle with strong, steady force to create a gap between the cover and frame.
  • If trouble occurs, apply more heat following iOpener instructions carefully to avoid overheating.

Insert an opening pick into the created gap.

Step 4 | Separate the right adhesive

Step 4 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Slide a pick along the right edge, moving it back and forth to separate the adhesive.

  • Leave the pick inserted at the bottom right corner to prevent resealing of the adhesive.

Step 5 | Heat the bottom edge

Step 5 image

Apply a iOpener to the bottom edge of the back cover and heat it for 2 minutes.

Step 6 | Separate the corner adhesive

Step 6 image
Thumbnail 1
Thumbnail 2
Thumbnail 3
  • Insert a second opening pick at the bottom right corner.
  • Rotate the opening pick around the bottom right corner to separate the adhesive.

Step 7 | Separate the bottom adhesive

Step 7 image
Thumbnail 1
Thumbnail 2

Insert the opening pick into the top right corner.

  • Move the pick down and to the left, separating the adhesive at that point.
  • Leave the pick in place, preventing re-adhesion of the adhesive.

Step 8 | Heat the left edge

Step 8 image

Use a iOpener to heat the left edge of the back cover for 2 minutes.

Step 9 | Separate the corner adhesive

Step 9 image
Thumbnail 1
Thumbnail 2

Hold the opening pick at the bottom left corner and gently rotate it to loosen the adhesive.

Be careful not to apply too much pressure, which may damage the surrounding components.

Step 10 | Separate the left adhesive

Step 10 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Insert a third opening pick at the bottom left corner.

  • Slide the pick toward the top left corner to separate the adhesive.
  • Leave the pick in place, above the left edge, to prevent resealing.

Step 11 | Heat the top edge

Step 11 image

Apply iOpener heat to the top edge of the back cover for 2 minutes.

Step 12 | Separate the corner adhesive

Step 12 image
Thumbnail 1
Thumbnail 2
Thumbnail 3
  • Insert a fourth opening pick at the top left corner.
  • Rotate the pick around the top left corner to loosen the adhesive.

Step 13 | Separate the top adhesive

Step 13 image
Thumbnail 1
Thumbnail 2
  • Insert a pick into the top right corner and slide it towards the edge to loosen the adhesive.
  • Leave the pick in place at the top right corner to maintain separation of the adhesive.

Step 14 | Separate the flash adhesive

Step 14 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Risk of damage to rear cameras: avoid pushing on lens surfaces.

  • Line up an opening pick with the flash cutout.
  • Slide under top edge, snagging adhesive, until visible through the cutout.
  • Continue sliding toward bottom until adhesive separates completely from back cover.

Step 15 | Remove the back cover

Step 15 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Grab and remove the back cover.

If your cover is still sticking to the frame, carefully slide an opening pick around the perimeter until it separates completely.

  • During reassembly, power on your phone and test all functions before sealing it up.
  • Prior to continuing work, ensure your phone is powered down completely.

Remove any adhesive chunks using a pair of tweezers or your fingers.

If needed, apply heat and isopropyl alcohol (90% or greater) to aid in adhesive removal.

  • If using custom-cut adhesives, refer to this guide for instructions.
  • If using double-sided tape, refer to this guide for instructions.

Step 16 | Disconnect the wireless charging coil

Step 16 image
Thumbnail 1
Thumbnail 2

Use a spudger to pry up the wireless charging coil press connector from the motherboard.

  • To reattach: align the connector carefully and press down on one side until it clicks, then repeat on the other side.
  • Do not press in the middle or misalign the connector — risk of pin damage.

Step 17 | Remove the wireless charging coil and loudspeaker screws

Step 17 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Remove the six Phillips head screws securing the wireless charging coil.

  • Use a Phillips screwdriver to remove these screws.

Be careful not to damage any nearby components during this process.

Next, remove the seven Phillips head screws securing the loudspeaker.

Step 18 | Remove the wireless charging coil and loudspeaker

Step 18 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Insert spudger into top left notch of loudspeaker.

  • Pry up to release loudspeaker from frame.

Step 19

Step 19 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Use your fingers to lift the loudspeaker away from the frame.

  • Remove the wireless charging coil and loudspeaker from the frame.

Apply gentle pressure around the perimeter of the loudspeaker to clip it securely during reassembly.

Step 20 | Disconnect the battery

Step 20 image
Thumbnail 1
Thumbnail 2

Position the spudger on the battery press connector and gently pry it away.

  • Focus on the connector's edge to prevent damage.
  • The connector should now be released from the motherboard.

Step 21 | Disconnect the earpiece speaker

Step 21 image
Thumbnail 1
Thumbnail 2

Use the spudger to gently pry up and release the earpiece speaker press connector.

Step 22 | Remove the earpiece speaker screws

Step 22 image
Thumbnail 1
Thumbnail 2

Remove the earpiece speaker's screws using a Phillips screwdriver.

  • The screws are five in total and have a length of 3.5 mm

Step 23 | Remove the earpiece speaker

Step 23 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Insert the flat end of your spudger between the bottom edge of the earpiece speaker and the silver shield on the motherboard.

Do not insert your spudger anywhere else, as you risk dislodging fragile surface-mounted components.

  • Twist the spudger to unclip the earpiece speaker from the frame.
  • Remove the earpiece speaker.

During reassembly, insert the top end of the earpiece speaker into the frame first before pressing down and clipping it back in.
