Samsung Galaxy J5 2017 Display Replacement
Replacing the screen without addressing warped frame issues may result in premature damage or uneven pressure on the new screen.
- Samsung Galaxy J5 screen replacement: discharge battery below 25% to minimize risk of fire/explosion if accidentally punctured.
- This guide only covers replacing the screen, leaving original chassis and motherboard in place. Be sure to verify your replacement screen's specifications before proceeding.
- Note: Some screens come with a pre-installed new chassis; follow a different procedure for these models.
- Replacement adhesive will be required for reassembly.
Step 1 | Display
Heat the glass with a hair dryer to loosen the adhesive.
- Insert thin tools between the glass and the plastic frame.
- Avoid inserting tools between the aluminum and plastic frame.
Step 2
Disconnect the connector by unclipping it.
- Lift the display from bottom to top.
- Remove the black snap-on lid.
Clean surfaces thoroughly of glue residues before installing replacement display.
- Install new replacement display.
