Samsung Galaxy J1 Volume Button Replacement

Insert a finger nail or plastic opening tool between the back cover and the device.

• Gently pry the rear cover off the back of the phone.

Insert your finger into the SIM card slot to gently pull it downward.

• Continue to pull until the SIM card is completely removed from its slot.
• The device shown in the picture has already had the SIM card and battery removed.

Remove the eleven 3 mm screws using a Phillips #00 screwdriver.

Be careful not to crack the glass screen or damage internal clips.

• Insert a plastic opening tool between the screen and back of the device.
• Gently slide the tool along the edges, starting at the bottom.
• Pry the main assembly from the midframe, taking care to avoid damage.

Insert the flat edge of a spudger and gently push the volume button outward.

Secure the volume button in place with your fingers before removal.

• Remove the volume button.
