Samsung Galaxy Note10+ Rear Camera Module Replacement

Insert the SIM eject tool, ejector bit, or a straightened paper clip into the small hole on the SIM card tray.

Press firmly but avoid applying excessive force — risk of damage to phone components.

• Allow the tray to fully eject from the phone.
• Remove the SIM card tray by pulling it out gently.

Power off your phone completely before starting disassembly.

• Apply an iOpener to the left edge of the rear cover for 1 minute.
• Alternatively, use a hair dryer, heat gun, or hot plate, but avoid overheating the phone:

The display and internal battery are susceptible to heat damage.

Apply suction cup as close to rear cover edge as possible, or cover with clear packing tape for better adhesion.

Use strong tape or superglue if suction cup fails to adhere.

• Pull up on suction cup with strong, steady force to create gap between rear cover and frame.
• If stuck, reapply heat and try again.

Once a gap is created, insert opening pick point into the gap.

Slide the opening pick along the left edge towards the bottom left corner.

Don't insert more than halfway or you risk damaging internal components.

• Leave the pick inserted in the bottom left corner to prevent adhesive re-sealing.

Continue heating and cutting around the remaining three sides of the phone.

• Leave an opening pick on each side to prevent resealing before moving to the next one.
• Repeat this process until the rear cover separates from the phone.

Remove the rear cover by lifting it straight up.

• Reinstall the rear cover following these instructions and replacing the adhesive.
• Ensure your device is powered on and functional before applying new adhesive or resealing.

If using Tesa tape, consult this separate guide for proper application.

Remove the wireless charging coil's five 4 mm screws using a Phillips screwdriver.

Use tweezers to lift up and flip back the metal shield over the battery connector.

Hold the metal shield aside and use the pointed end of a spudger to carefully pry up the battery connector.

Be gentle to avoid damaging the connector.

Use the pointed end of a spudger to carefully disconnect the wireless charging coil connector from the motherboard.

Flip the metal shielding upwards.

• Lift the wireless charging coil carefully, taking care not to break its connection to the device.
• The coil is held in place with a small amount of adhesive. Use gentle force to remove it completely.

Remove the loudspeaker by unscrewing the five 4mm Phillips screws

Remove the loudspeaker with a pair of tweezers.

• Use the pointed end of a spudger to disconnect the main interconnect cable from the motherboard.
• Disconnect the secondary interconnect cable from the motherboard.

• Use the pointed end of a spudger to disconnect the main interconnect cable from the daughterboard.
• Disconnect the secondary interconnect cable from the daughterboard.

Disconnect the interconnect cables from their connectors.

Remove the four 4mm screws from the top plastic cover using a Phillips screwdriver.

Use tweezers to lift and swing the top plastic cover upwards, then remove it from the phone.

Locate and carefully remove the touch layer connector using the pointed tip of a spudger.

• Remove the side button connector using the same pointed end of the spudger.

Disconnect the S-Pen charging coil connector using the pointed end of a spudger.

Insert the pointed end of a spudger into the connector and gently pry it away from the motherboard.

Locate the motherboard.

• Insert the pointed end of a spudger under one edge of the motherboard and gently pry it up.
• Grip the motherboard firmly with your fingers.
• Carefully lift the motherboard out.

Remove the tape covering the middle camera connector using a pair of tweezers.

Use the pointed end of a spudger to carefully disconnect the bottom camera connector.

• Next, disconnect the middle camera connector.

Disconnect the top camera connector with the pointed end of a spudger.

Remove the rear camera module using a pair of tweezers or your fingers.
