LG K20 PLUS Ear Speaker Replacement

Insert a fingernail or opening pick into the slot to release the plastic clips.

Be gentle to avoid damaging the clips.

• Lift the battery upwards by its edges.

Remove 11 Philips screws.

• Pull the midframe outwards using a fingernail or an opening pick in the gap between the digitizer and midframe.
• Disengage the clips on the bottom carefully, as the headphone jack passes through.
• Move the midframe outwards and downwards to disengage it from the headphone jack once all clips are free.

Use a Halberd spudger or an opening pick to carefully disconnect the front camera flex from its connector on the motherboard.

Risk of damaging the motherboard — exercise care.

• Disconnect the display flex cable using a Halberd spudger or an opening pick.
• Insert an opening pick between the motherboard and frame from the bottom, levering them apart carefully.
• Be cautious not to damage the long motherboard section.

The top motherboard is lightly adhered — apply gentle force only.

• Compare the original and replacement display assemblies after removing the motherboard.
• Some components may be pre-installed on the new assembly.

Apply heat to soften the adhesive.

• Insert a Jimmy between the flex cable and frame, detaching the cable from the adhesive.
• Use the tip of a metal spudger to carefully pry up the ear speaker.
