LG G5 Rear Camera Replacement

Pull the bottom end of the phone out of its body while pressing and holding the battery release button.

• Insert the sim card eject tool (0.8mm sim card eject head) into the small hole on the sim card tray.

• Press inward with some force to eject the tray — risk of damage if too much pressure is applied.

• Pull the sim card tray out of the phone.

Remove the 2 x 5.5mm Phillips #00 screws from the base of the phone.

Insert the plastic opening tool into the seam between the glass screen and the metal body.

Apply minimal force to pry the glass from the body, only a slight amount is required.

Insert Spudger into the space between body and screen.

• Push inward to separate screen further.
• Slowly slide Spudger up phone's edge until screen pops out.

When reinstalling, press edges from top to bottom for a secure fit.

Separate the display from the main assembly by gently peeling them apart.

Insert plastic opening tool between camera-ribbon connector and motherboard, then gently pull up.

Remove the camera with tweezers, taking care not to touch the ribbon.

• Use a gentle prying motion with the tweezers.
• Avoid touching the detached ribbon.
