Google Pixel 9 Pro XL Screen Replacement

This repair guide is by iFixit staff and not endorsed by Google; learn more about our guides here.

  • This repair replaces a broken, cracked, or unresponsive screen on your Google Pixel 9 Pro XL.
  • If the replacement screen doesn't come with adhesive installed, you'll need additional screen adhesive to complete this repair.
  • Any repair may compromise water resistance; reapplying adhesive carefully is crucial for retaining it afterwards.

Step 1 | Safety precautions

Google Pixel 9 Pro XL Screen Replacement - Step 1: Safety precautions
Google Pixel 9 Pro XL Screen Replacement - Step 1: Safety precautions Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 1: Safety precautions Thumbnail 2

Allow the battery to deplete below 25% to prevent potential fire hazards from a damaged lithium-ion cell.

  • Remove any connected cables from your Pixel.
  • Powder down the device completely before proceeding with the repair.

Step 2 | Tape over any cracks

Google Pixel 9 Pro XL Screen Replacement - Step 2: Tape over any cracks
Google Pixel 9 Pro XL Screen Replacement - Step 2: Tape over any cracks Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 2: Tape over any cracks Thumbnail 2

Glass shards can cause injury, so it's essential to handle them with care.

  • Apply overlapping strips of packing tape directly to the cracked screen glass.
  • Ensure the tape only covers the glass and not the phone frame.

Wear safety glasses to protect your eyes from any loose glass particles.

Step 3

Google Pixel 9 Pro XL Screen Replacement - Step 3
Google Pixel 9 Pro XL Screen Replacement - Step 3 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 3 Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 3 Thumbnail 3

Never apply excessive heat to the phone, as this can cause damage to the battery and plastic components.

  • Apply gentle heat to the screen using a hair dryer, heat gun, or hot plate until it's almost too hot to touch.
  • The adhesive should soften, making it easier to separate from the frame.

Step 4 | Apply a suction handle

Google Pixel 9 Pro XL Screen Replacement - Step 4: Apply a suction handle
Google Pixel 9 Pro XL Screen Replacement - Step 4: Apply a suction handle Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 4: Apply a suction handle Thumbnail 2

Attach a suction handle to the middle of the screen's top edge.

Step 5 | Screen information

Google Pixel 9 Pro XL Screen Replacement - Step 5: Screen information
Google Pixel 9 Pro XL Screen Replacement - Step 5: Screen information Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 5: Screen information Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 5: Screen information Thumbnail 3

When using an opening pick, do not insert it deeper than 3mm into the device.

  • Measure 3mm from the tip and mark the opening pick with a permanent marker.
  • Or, attach a coin to the end of the pick, positioned 3mm from the tip using tape.

Step 6 | Insert an opening pick

Google Pixel 9 Pro XL Screen Replacement - Step 6: Insert an opening pick
Google Pixel 9 Pro XL Screen Replacement - Step 6: Insert an opening pick Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 6: Insert an opening pick Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 6: Insert an opening pick Thumbnail 3

Be patient when inserting an opening pick as it can be challenging.

  • Reheat the screen if it feels stuck during insertion.
  • Pull up on the suction handle with strong, steady force to create a gap between the screen and frame.
  • Insert the tip of an opening pick under the screen, ensuring it's underneath the attached plastic frame.

Step 7 | Separate the screen adhesive

Google Pixel 9 Pro XL Screen Replacement - Step 7: Separate the screen adhesive
Google Pixel 9 Pro XL Screen Replacement - Step 7: Separate the screen adhesive Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 7: Separate the screen adhesive Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 7: Separate the screen adhesive Thumbnail 3

Insert an opening pick into the top edge and gently slide it downward, separating the adhesive as you go.

Step 8

Google Pixel 9 Pro XL Screen Replacement - Step 8
Google Pixel 9 Pro XL Screen Replacement - Step 8 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 8 Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 8 Thumbnail 3

Slide the opening pick along the screen's edges to loosen remaining adhesive.

  • Work your way around the entire screen, applying gentle pressure as needed.
  • Be cautious of any stubborn areas requiring extra attention.

Step 9 | Prop up the screen

Google Pixel 9 Pro XL Screen Replacement - Step 9: Prop up the screen
Google Pixel 9 Pro XL Screen Replacement - Step 9: Prop up the screen Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 9: Prop up the screen Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 9: Prop up the screen Thumbnail 3

Flip the screen over the right edge of your phone and prop it up with the suction handle.

Be careful not to strain the display cable, located near the bottom right corner.

  • If the screen feels stuck, go back around the perimeter with an opening pick to separate any remaining adhesive.

Step 10 | Disconnect the screen

Google Pixel 9 Pro XL Screen Replacement - Step 10: Disconnect the screen
Google Pixel 9 Pro XL Screen Replacement - Step 10: Disconnect the screen Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 10: Disconnect the screen Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 10: Disconnect the screen Thumbnail 3

Use angled tweezers to gently lift the top edge of the screen cable bracket.

  • Continue prying until the bracket is removed.

Step 11

Google Pixel 9 Pro XL Screen Replacement - Step 11
Google Pixel 9 Pro XL Screen Replacement - Step 11 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 11 Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 11 Thumbnail 3

Careful handling is required to avoid damaging nearby surface-mounted components.

  • Insert the spudger point under the left edge of the screen cable press connector and pry up to release it.
  • Remove the screen.

Step 12 | Screen information

Google Pixel 9 Pro XL Screen Replacement - Step 12: Screen information

The Pixel's screen is extremely fragile and can be damaged by even minor scratches or dents.

  • Grip the screen by its edges to prevent applying pressure to the sensitive area.
  • Place the screen on a soft, lint-free cloth to prevent damage from foreign objects touching the bottom of the screen.

Step 13 | Remove all the old screen adhesive

Google Pixel 9 Pro XL Screen Replacement - Step 13: Remove all the old screen adhesive
Google Pixel 9 Pro XL Screen Replacement - Step 13: Remove all the old screen adhesive Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 13: Remove all the old screen adhesive Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 13: Remove all the old screen adhesive Thumbnail 3

Damage to fragile components near the frame's perimeter can occur if not careful.

  • Use a spudger to scrape up old screen adhesive from the frame's perimeter.
  • Rid old adhesive by rolling it onto itself while working slowly.
  • Clean perimeter with isopropyl alcohol and microfiber cloth, removing all residue.
  • Ensure frame is completely dry before continuing.

Step 14 | Orient the adhesive

Google Pixel 9 Pro XL Screen Replacement - Step 14: Orient the adhesive
Google Pixel 9 Pro XL Screen Replacement - Step 14: Orient the adhesive Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 14: Orient the adhesive Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 14: Orient the adhesive Thumbnail 3

Verify if new screen has pre-installed adhesive.

  • Measure and cut custom adhesive film if needed.
  • Liner Removal Tool removes blue protective liner.
  • Apply adhesive to the frame's perimeter, aligning with corresponding groove.
  • Position clear side of liner facing down on bottom edge of phone frame.
  • Align cutouts in liner over spring contacts.
  • Remove blue protective liner from new screen.
  • Install new screen, ensuring correct orientation and adhesive alignment.

Step 15 | Apply the screen adhesive

Google Pixel 9 Pro XL Screen Replacement - Step 15: Apply the screen adhesive

Peel down the top half of the larger, clear liner to expose the adhesive.

Do not remove the entire liner yet.

Step 16

Google Pixel 9 Pro XL Screen Replacement - Step 16
Google Pixel 9 Pro XL Screen Replacement - Step 16 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 16 Thumbnail 2

Take your time when aligning the adhesive with the frame.

  • Keep the larger, clear liner folded towards the bottom of the phone.
  • Lay the exposed top edge of the adhesive onto the frame, using the lip for alignment.
  • Gently press down on the top edge with your fingers to secure it in place.

Step 17

Google Pixel 9 Pro XL Screen Replacement - Step 17
Google Pixel 9 Pro XL Screen Replacement - Step 17 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 17 Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 17 Thumbnail 3

Slowly apply the remaining adhesive to the frame, peeling off the large clear liner as needed.

Step 18 | Secure the screen adhesive

Google Pixel 9 Pro XL Screen Replacement - Step 18: Secure the screen adhesive
Google Pixel 9 Pro XL Screen Replacement - Step 18: Secure the screen adhesive Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 18: Secure the screen adhesive Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 18: Secure the screen adhesive Thumbnail 3

Use the flat end of a spudger to firmly press around the perimeter of the adhesive and secure it to the frame.

Step 19

Google Pixel 9 Pro XL Screen Replacement - Step 19
Google Pixel 9 Pro XL Screen Replacement - Step 19 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 19 Thumbnail 2

Remove the blue liner by gripping its top left corner with tweezers.

  • Peel the liner away from the frame, taking care not to let any adhesive peel up.
  • If adhesive starts to lift, gently press it back onto the frame and secure it using the flat end of a spudger.

Step 20

Google Pixel 9 Pro XL Screen Replacement - Step 20
Google Pixel 9 Pro XL Screen Replacement - Step 20 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 20 Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 20 Thumbnail 3

Press the flat end of a spudger firmly around the perimeter of the adhesive to secure it to the frame.

Step 21 | Connect the replacement screen

Google Pixel 9 Pro XL Screen Replacement - Step 21: Connect the replacement screen

Place the new screen display-side-down beside the phone, positioning it to the right for easy cable reconnection.

Step 22

Google Pixel 9 Pro XL Screen Replacement - Step 22
Google Pixel 9 Pro XL Screen Replacement - Step 22 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 22 Thumbnail 2

Careful handling is crucial when working with the screen cable to avoid straining it.

  • Hold the screen at an angle to facilitate the alignment of the screen cable.
  • Align the screen press connector over its socket and gently click one side into place, then do the same for the other side.
  • Avoid pressing down in the middle, as this can bend pins and cause permanent damage if the connector is misaligned.
  • Firmly press the bottom edge of the screen cable bracket into its cutout and secure it with a click on the top edge.

Step 23 | Remove any small liners

Google Pixel 9 Pro XL Screen Replacement - Step 23: Remove any small liners
Google Pixel 9 Pro XL Screen Replacement - Step 23: Remove any small liners Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 23: Remove any small liners Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 23: Remove any small liners Thumbnail 3

Leave the perimeter display adhesive liners in place.

  • Inspect the replacement screen for small plastic liners near the front facing camera and screen cable.
  • Remove these liners using your fingers, identifying them by their plastic pull tabs.

Be careful not to damage the screen during liner removal.

Step 24 | Remove the screen adhesive liner

Google Pixel 9 Pro XL Screen Replacement - Step 24: Remove the screen adhesive liner
Google Pixel 9 Pro XL Screen Replacement - Step 24: Remove the screen adhesive liner Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 24: Remove the screen adhesive liner Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 24: Remove the screen adhesive liner Thumbnail 3

Remove tweezers and fingers from the underside of the screen.

  • Remove the two remaining blue liners using either tweezers or your fingers.

Step 25

Google Pixel 9 Pro XL Screen Replacement - Step 25
Google Pixel 9 Pro XL Screen Replacement - Step 25 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 25 Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 25 Thumbnail 3

Remove the two liner strips from the frame using tweezers or your fingers.

  • Note: For frames with applied adhesive, carefully hold the screen up to remove the right liner.
  • Use tweezers or your fingers to gently pry out the remaining liner from the frame.

Step 26 | Secure the screen with its adhesive

Google Pixel 9 Pro XL Screen Replacement - Step 26: Secure the screen with its adhesive
Google Pixel 9 Pro XL Screen Replacement - Step 26: Secure the screen with its adhesive Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 26: Secure the screen with its adhesive Thumbnail 2

Flip the screen carefully onto the frame.

Step 27

Google Pixel 9 Pro XL Screen Replacement - Step 27
Google Pixel 9 Pro XL Screen Replacement - Step 27 Thumbnail 1
Google Pixel 9 Pro XL Screen Replacement - Step 27 Thumbnail 2
Google Pixel 9 Pro XL Screen Replacement - Step 27 Thumbnail 3

Firmly press the screen around its perimeter to secure it to the frame.

  • Power on your Pixel for the first time after the repair and ensure the phone is laying flat.
  • Avoid touching the screen with any objects, such as fingers, plastic liners, or screen protectors.
Check COD Availability

Enter your pincode to see if Cash on Delivery is available in your area.

Please enter a valid 6-digit pincode
S
Sakshi • Support
Online • replies in a few seconds
Hi there! I am Sakshi from the Sahii support team. I can help with active orders, live tracking, wallet questions, and genuine mobile spare parts. What would you like me to check?
Sakshi is checking this
