Google Pixel 10 Pro XL Front Camera Replacement

Note that any repair may compromise the phone's water resistance.

  • The Google Pixel 10 Pro XL front camera replacement guide was created by iFixit staff, but has not been endorsed by Google. Learn more about our guides here.
  • This guide is for replacing the selfie camera (also known as the front camera) in your device.
  • If you experience blurry or fuzzy camera images, or complete loss of function, consider replacing the camera.
  • You will need new back glass and front camera adhesive to complete this repair.

Step 1 | Prepare your Pixel for disassembly

Step 1 image
Thumbnail 1
Thumbnail 2

Ensure the Pixel's battery is drained to at least 25% or lower.

  • Disconnect all cables from the device.
  • Power down the phone completely.

Step 2 | Cracked glass preparation

Step 2 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Cracked back glass can cause injury or complicate disassembly.

  • Apply packing tape strips across cracked glass, ensuring it's fully covered.
  • A single strip of tape should run along the bottom edge, big enough for a suction cup to fit.
  • Only cover the glass itself; do not stick tape to the frame.
  • Consider wearing safety glasses to protect eyes from loose glass.

Step 3 | Heat the bottom edge

Step 3 image

Careful: improper use of a heat gun may damage the display and/or battery.

  • Heat an iOpener for 2 minutes on the bottom edge of the back glass.
  • Alternatively, use a hair dryer or heat gun to soften the adhesive.

Follow proper usage instructions when using a heat gun to avoid damage.

Step 4 | Apply a suction handle

Step 4 image
Thumbnail 1
Thumbnail 2

Attach a suction handle to the center of the back glass's lower edge, as close to the edge as possible.

Step 5 | Insert an opening pick

Step 5 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Apply firm pressure to the suction handle until a small gap appears between the back glass and the .

  • Slide the tip of an opening pick into the created gap.

Step 6 | Back glass adhesive information

Step 6 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Use the provided image for reference when separating the adhesive around the perimeter of the frame.

  • Avoid damaging the cable connected near the power button.
  • Insert your pick carefully, excluding the area near the power button where the cable is located.

Step 7 | Separate the bottom edge adhesive

Step 7 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Apply heat if the back glass feels stuck.

  • Slide an opening pick along the bottom edge to separate the adhesive.
  • Leave the pick in place, especially at the bottom left corner, to prevent the adhesive from re-sealing.

Step 8 | Separate the bottom left adhesive

Step 8 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Insert a pick under the bottom left corner.

  • Slide the pick up the left edge until it reaches the power button.
  • Leave the pick inserted to prevent re-sealing of the adhesive.

Step 9 | Separate the right edge adhesive

Step 9 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Insert a third pick under the bottom right corner of the back glass.

  • Slide the pick up the right edge.
  • Leave it inserted under the top right corner.

Step 10 | Separate the top edge adhesive

Step 10 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Insert a pick under the top right corner.

  • Slide the pick along the top edge and slightly around the top left corner.
  • Stop at the bottom of the camera bump.

Do not remove the back glass yet, as it is still connected by a ribbon cable.

Step 11 | Prop up the back glass

Step 11 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Flip the back glass over the left side of the phone.

  • Use a suction handle (or a sturdy object) to prop it up.
  • If stuck, go around the perimeter with an opening pick and separate any remaining adhesive.

Step 12 | Remove the bracket screws

Step 12 image
Thumbnail 1
Thumbnail 2

Remove the two Torx Plus 3IP screwdriver screws securing the back glass connector bracket using a Torx Plus 3IP screwdriver.

  • The screws are approximately 2.3 mm in length.

Step 13

Step 13 image
Thumbnail 1
Thumbnail 2

Do not scratch or smudge the rear cameras.

  • Remove the bracket using either tweezers or your fingers.

Step 14 | Disconnect the back glass

Step 14 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Insert the point of the spudger between the connectors.

  • Pry up on the battery connector.
  • Deseat the back glass press connector.

Step 15 | Remove the back glass

Step 15 image

Remove back glass.

Step 16 | Remove the motherboard cover screws

Step 16 image
Thumbnail 1
Thumbnail 2

Use a Torx Plus 3IP screwdriver to remove the four motherboard cover screws.

  • The screws are 5.0 mm long.
  • Remove all four screws before proceeding.

Step 17 | Remove the motherboard cover

Step 17 image
Thumbnail 1
Thumbnail 2

Remove motherboard cover.

Step 18 | Disconnect the front camera

Step 18 image
Thumbnail 1
Thumbnail 2

Use the point of a spudger to gently pry up and release the front camera press connector.

Step 19 | Remove the front camera cover screw

Step 19 image
Thumbnail 1
Thumbnail 2

Remove the Torx Plus 3IP screwdriver-secured 5.0 mm-long screw.

  • Hold the screwdriver firmly in place and turn it counterclockwise until the screw is removed.

Step 20 | Remove the front camera cover

Step 20 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Insert the spudger into the camera bracket's clip.

Push upwards on the clip to release it.

  • Continue pushing until the cover is freed.

Step 21 | Remove the front camera

Step 21 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Remove the front camera by prying it up with a flat tool, starting at the top edge.

  • Insert the tip of a plastic opening pick into the recess under the front camera.
  • Gently pry the front camera upwards to release its adhesive and remove it.

Step 22 | Disassembly complete

Step 22 image

Reassembly of your phone is now underway.

Step 23 | Remove the old front camera adhesive

Step 23 image
Thumbnail 1
Thumbnail 2

Scrape away old front camera adhesive with the spudger tip, then use tweezers to carefully lift out residue.

Step 24

Step 24 image

Risk of damage: Ensure the camera lens is not exposed to the cleaning solution.

  • Wrap a spudger in a microfiber cloth and apply one drop of high-concentration (>90%) isopropyl alcohol.
  • Clean up any adhesive residue from the front camera recess with gentle, targeted strokes.
  • Allow the alcohol to dry completely before continuing.

Step 25 | Install new front camera adhesive

Step 25 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Remove the large clear liner from the front camera adhesive.

  • Gently place the liner into its recess.
  • Use a spudger to press down firmly on the adhesive, securing it in place.

If the adhesive starts to peel up with the liner, lay it flat and repress it before trying again to avoid damage or air bubbles.

Slowly peel up and remove the remaining liner.

Step 26 | Remove any protective caps

Step 26 image

Remove the protective cap from the new front camera.

Step 27 | Put the front camera in its recess

Step 27 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Locate the front camera and gently press it into its designated recess.

  • The cable should face downwards during this process.
  • Ensure the camera is securely seated in its position.

Step 28 | Install the front camera bracket

Step 28 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Avoid accidental damage to the rear cameras.

  • Align the front camera bracket with the frame's lip and slide its top corners underneath.
  • Press the clip firmly in place to secure it.

Step 29

Step 29 image
Thumbnail 1
Thumbnail 2

Insert the Torx Plus 3IP screwdriver and drive in the 5.0 mm-long screw securing the front camera cover.

Step 30 | Reconnect the front camera

Step 30 image
Thumbnail 1
Thumbnail 2

Press the front camera press connector onto its socket with your finger.

  • Start by pressing down on one of the shorter sides until you hear a click.
  • Next, press down on the other side to secure it in place.

Step 31 | Place the motherboard cover

Step 31 image
Thumbnail 1
Thumbnail 2

Reattach the motherboard cover.

Step 32 | Install the motherboard cover screws

Step 32 image
Thumbnail 1
Thumbnail 2
  • Install the motherboard cover using a Torx Plus 3IP screwdriver.
  • Secure the cover with four 5.0 mm-long screws.

Step 33 | Remove the old back glass adhesive

Step 33 image
Thumbnail 1
Thumbnail 2

Remove all old adhesive and its residue from the frame thoroughly.

  • Set aside any removed material for future disposal.

A clean frame is crucial for proper installation.

  • Allow new adhesive to dry completely, ensuring a flat surface.
  • This will achieve an optimal seal around the back glass.

Step 34

Step 34 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Be extremely cautious when removing back glass adhesive to avoid damaging the battery or fragile components.

  • Use a spudger's point to gently remove old screen adhesive from the frame, rolling it onto itself as you scrape.
  • If a large chunk forms, carefully pull it away with tweezers in the opposite direction of scraping.
  • For smaller chunks, apply one drop of high-concentration (>90%) isopropyl alcohol and scrape them up with your spudger.

Step 35

Step 35 image

Wrap a microfiber cloth around a spudger.

  • Use the spudger and high-concentration isopropyl alcohol (>90%) to clean up remaining adhesive residue from the frame.
  • Apply more drops of alcohol as necessary, then let it dry completely before continuing.

Step 36

Step 36 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Reinstalling original back glass? Clean it using same procedures as previous two steps.

Step 37 | Orient the adhesive

Step 37 image
Thumbnail 1
Thumbnail 2

Position the back glass adhesive over the phone's frame and orient it with the rear camera cutout aligned.

  • Check the adhesive's position by holding it above the frame.
  • Use the liner's rear camera cutout to ensure correct alignment.

Incorrect application will require a new adhesive and restart of the process.

Step 38

Step 38 image

Peel the top half of the larger, clear liner back to reveal the adhesive.

  • Do not fully remove the liner at this point.

Step 39 | Install the back glass adhesive

Step 39 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Take your time when aligning the adhesive with the frame as it's very sticky and can't be moved once applied.

  • Lay the exposed top edge of the adhesive onto the frame, folded clear liner towards the bottom of the phone.
  • Use the lip of the frame to help align the adhesive.
  • Gently press down on the top corners to secure the adhesive once it's properly aligned.

Step 40

Step 40 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Apply remaining adhesive to the frame, pressing firmly while removing the clear liner.

Step 41

Step 41 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Press down firmly on the adhesive with a spudger to secure it to the frame.

Step 42 | Remove the large colored liner

Step 42 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Peel up and remove the large colored liner, gripping from the cutout near the top edge.

  • If the adhesive starts to come up, check that the spudger has pushed all of it into place.
  • Hold down any stubborn areas with the point of your spudger as you remove the liner.

Step 43 | Remove any liners from the back glass

Step 43 image
Thumbnail 1
Thumbnail 2

Remove protective liners and tape on the underside of the new back glass.

  • Check carefully for varying pieces in different locations.
  • Focus removal efforts on front camera cutouts and bottom edge.
  • The liners can usually be identified by pull tabs.

Step 44 | Prop up the back glass

Step 44 image

Position the suction handle at the back glass and secure the phone with it on the left side.

  • The cable should be near its connector for safe removal.
  • Alternatively, use a sturdy object like books to prop up the back glass.

Step 45 | Reconnect the back glass and battery

Step 45 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Press down on a short side of the back glass connector until it clicks into place.

Avoid pressing down in the middle or on misaligned connectors to prevent pin bending and damage.

Repeat the process for the other short side, then move to the battery press connector.

Step 46

Step 46 image
Thumbnail 1
Thumbnail 2

Reattach the back glass connector cover.

Step 47

Step 47 image
Thumbnail 1
Thumbnail 2

Install Torx Plus 3IP screwdriver. Secure cover with two 2.3 mm-long screws.

Step 48 | Secure the adhesive

Step 48 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Press the adhesive firmly in place with a spudger.

  • Power on your device and test all functions.
  • If issues arise, perform basic troubleshooting steps.
  • Power down completely before continuing work.

Step 49 | Remove the remaining liners

Step 49 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Remove any remaining liners from the back glass adhesive.

  • If adhesive peels with liner, ensure all adhesive is fully seated with your spudger.
  • Hold down peeling adhesive with spudger tip if necessary.

Step 50 | Install the back glass

Step 50 image
Thumbnail 1
Thumbnail 2
Thumbnail 3

Flip the back glass onto the frame and press it firmly into place.

  • Hold your phone up and squeeze firmly around the perimeter to strengthen the bond.
  • To achieve an even stronger bond, use e.g., books or screen vise clamps.
Check COD Availability

Enter your pincode to see if Cash on Delivery is available in your area.

Please enter a valid 6-digit pincode
